Eumig Mark S 810 D High Quality Sound Projector
A dual gauge sound projector. Plays Super8/Single8 and standard8.
Lens: Vario Eupronet 1,3/15-30 mm.May also be equipped with some other Eupronet zoom lens.
EUMIG FL-1000 mju P Service Manual EUMIG 614D Users Guide EUMIG FL-1000 mju P Service Manual EUMIG S 931 (S931) Users Guide EUMIG S 910 (S910) Users Guide EUMIG MARK S 710D Schematics EUMIG MARK S 710D Quick Start Guide EUMIG C3 Users Guide EUMIG MARK-S-710D Users Guide EUMIG 624D Users Guide EUMIG MARK 610D LUX Users Guide EUMIG MARK S 807 (S807) Users Guide EUMIG. Request any owner's manual, instructions book, user's guide, service manual, schematics, parts list.
Halogen lamp 12 V/100 W type EFP
Sound: mono ( record&playback ), fade in / fade out, sound-on-sound, mixing from external source ( microphone 0,3-150 mV, 22 kΩ; line in 50 mV - 3 V, 1 MΩ )
Amplifier 15W, option for external amplifier ( line out 0,5-1,5 V, 50 kΩ )
Internal loudspeaker
Option for external loudspeaker ( 4 - 8 Ω, 10W )
Auto threading
Forward/backward projection
Speeds: 18 fps and 24 fps
Eumig P8 Dual Manual Transmission
Reel capacity: 180m/600ft
Weight appx. ???
Accessories: Universal reel; 8mm to super8 stepper for the front arm spindle; microphone; 6 m reel of magnetic striped film; film head trimmer/clipper.
Optional accessories: Eumig Serie 600 Daylight Viewer; Eumig LS-800 loudspeaker; Universal re-recording lead ( a cord + four adapters ).
Comments[edit]
Eumig P8 Dual Manual Instructions
Eumig P8 Dual Manual For Sale
Changing between standard8 and S-type film formats requires changing the gate assembly and sprocket wheel set. If You are considering to buy this projector You should check that both sets are present. The second set of sprocket wheels is stored on the inner side of the removable front panel and the additional gate assembly is in a horizontal slot in the body, also under the front panel. When changing the gate assembly, the knob at the rear of the projector should be manually turned to position where the red dot is up.
